Rhino PD-45 Air Post Driver
The term light duty does not reflect the durability of the PD-45. At just 46 pounds and with a 2-1⁄2" piston, the ruggedly designed PD-45 delivers the performance only dreamed of by other drivers. The PD-45 is ideally suited for driving T-Posts, ground rod, tent stakes, grape stakes, delineator posts, form pins and fence posts up to 2-7⁄8".
There are no adpators available for the PD-45SF as it has a specific design criteria for specific silt fencing applications. A special silt fence chuck (71314) is required for driving fabric attached silt fence (included).
- Free Shipping via UPS Ground in Continental U.S.
- Made in U.S.A. Quality and Reliability.
Get a Kit
- Contains all essential tools for the job
- Makes transportation easy
- Preserve warranty with Filter-Lubricator
- See All Kits Below
PD-45 Post Drivers
| Part | Description | Price |
|---|---|---|
| 70012 |
PD-45 Post Driver Sold only in kit - See Below |
QUOTE Add |
| 70018 |
PD-45SF Silt Fence Post Driver Sold only in kit - See Below |
QUOTE Add |
Accessories and Adaptors
| Part | Description | Price |
|---|---|---|
| 600000 | Throttle Valve Kit with 5' hose whip* | $400.00 Add |
| 71199 | 15'-2" Hose Whip Assembly | $146.56 Add |
| 601128 | Filter-Regulator-Lubricator* For operator safety and post driver protection |
$416.78 Add |
| 225001 | Carrier for Filter-Regulator-Lubricator* | $208.39 Add |
| 225005 | Filter-Regulator-Lubricator and Carrier pre-assembled Both 225001 and 601128 |
$654.94 Add |
| 70600 | 2-1⁄2" ID Chuck Adaptor | $184.80 Add |
| 70601 | 2" ID Chuck Adaptor | $184.80 Add |
| 70602 | 1-1⁄2" ID Chuck Adaptor | $184.80 Add |
| 70603 | 1" ID Chuck Adaptor | $184.80 Add |
| 70606 | Channel Post Chuck Adaptor - 1.2-1.5 lbs/ft Posts Click here for inside dimensions |
$184.80 Add |
| 71260 | 2" Drive Cap for Schedule 40 Pipe with T-Bar and Clip | $303.43 Add |
| 71261 | 2-1⁄2" Drive Cap for Schedule 40 Pipe with T-Bar and Clip | $303.43 Add |
| 71199 | 15' 2" Hose Whip | $146.56 Add |
| 71314 | PD-45 Silt Fence Master Chuck Assy | QUOTE Add |
* Required for operation
Miscellaneous Accessories
| Part | Description | Price |
|---|---|---|
| 71200 | Transport Cart | QUOTE Add |
| 607000 | Hose Assembly 3⁄4" and up to 25' Hose. Includes assembly, labor and all parts EXCEPT hose. Add 605006 x number of feet of hose needed. |
$72.14 Add |
| 605006 | 3⁄4" Extra Hose Price per foot |
$4.52 Add |
| 100048 | Air Hose Assembly - 100' x 3⁄4" | $489.90 Add |
Kit Packages
All kits include: 70012 - PD-45 Light Duty Post Driver with 3" ID Master Chuck; 600000 - Throttle Valve Kit, with 5'2" Hose Whip; 71199 - 15'2" Hose Whip; 601128 - Filter Regulator Lubricator
|
|
|
|
 |
 |
Rhino PD 45 Economy Kit
Simply the basics. This kit is designed to provide the simple requirements to begin post driving.
| Part Number | Description/Contents | Price |
|---|---|---|
| 71272 | Additional items included:
Free ground shipping in the continental United States. |
$3,620.00 Add |
Rhino PD 45 Utility Kit
Designed to outfit a utility vehicle with the essential elements to allow crews to quickly and efficiently disembark a vehicle and perform required tasks.
| Part Number | Description/Contents | Price |
|---|---|---|
| 71276 | Additional items included:
Free ground shipping in the continental United States. |
$5,212.00 Add |
Rhino PDT 45 Transport Kit
Full Kit Ready to Go. Transport your Driver, Chucks and Accessories. Choice of 4 Chuck Adaptors.
| Part Number | Description/Contents | Price |
|---|---|---|
| 71215 | Additonal item included:
Free ground shipping in the continental United States. * Chuck adapter selection is customizable. |
$4,540.00 Add |
Rhino PDT 45 Total Solution Package
Full purpose transportable kit. Ready to tackle any job quickly. Choice of 4 Chuck Adaptors.
| Part Number | Description/Contents | Price |
|---|---|---|
| 71268 | Additional items included:
Free ground shipping in the continental United States. * Chuck adaptor selection is customizable. |
$6,190.00 Add |
Additional Available Kits
|
71340 |
PD-45 Fence Post Kit Same as Economy Kit - with 70601 - PD-45 2" ID Chuck Adaptor |
$5,212.00 Add |
Specifications
Top Cover:
Ductile iron casting, high in strength and ductility has a 1" (25.4 mm) diameter handle designed into the cover for easy handling and carrying. O-Ring sealed.
Body:
Ductile iron casting, with excellent wear resistant characteristics. The air inlet is cast into the body and tapped with 3⁄4" NPT female threaded ports, along with 1" (25.4 mm) diameter ergonomically designed side handles for easy handling and carrying. Chuck bolts pass thru the lower body flange into tapped holes in the chuck mounting plate allowing special chucks to be made in a wide variety of shapes and sizes.
Piston:
2-1⁄2" - Alloy steel heat treated with a ground surface with hard chrome plate. Designed with 2 round valve ports to give better lubrication and load distribution to the valve ring while running.
Master Chuck:
The 3" (76.2 mm) I.D. master chuck is of an all welded, reinforced steel and tubing construction. The chuck is equipped with extra long chuck adapter attachment lugs.
Fasteners:
S.A.E. Grade 5 bolts with belleville lock washers. All fasteners are plated.
Throttle Valve:
Each unit includes a Rhino Stainless Steel Throttle Valve. The valve is equipped with a lever lock for safety.
Chuck Adapters:
Standard chuck adapters are available in the following sizes: 1" (25.4 mm) I.D., 1 1⁄2" (38.1 mm) I.D., 2" (50.8 mm) I.D., 2 1⁄2" ( 63.5 mm) I.D. and a channel post adapter for 1.2 to 1.5 lbs/ft posts.
Air Consumption:
30 CFM (0.85 m3/min) @ 90 PSI (6.4 kg/cm2).
Weight:
46lbs.
Height:
21”
