Highest Power, Durability & Precision, Reversible

Designed for super intensive drilling, reaming and tappingof mild steel, cast iron with high durability and precision in industrial maintenance and production applications

Highest power with a durable and powerfull Air motor 1.2 Hp (890 W) or 2.8 Hp (2100 W).
Fast with high free speed
High capacity reversible corner drill
Excellent durable gearbox ensures the strong drilling

Take advantages of this CP1820R range of durable and precise reversible corner drills. The CP1820R range is defined by 2 models with 1.2 Hp (890 W) to 2.8 Hp (2100 W) pneumatic motor from 380 to 480 RPM and from 78.4 Nm (57.8 ft.lb) to 196.0 Nm (144.6 ft.lb) stall torque. Morse tapper socket are form N 2 to N 3. CP1820R reversible corner drills cover a large variety of applications like drilling, reaming & tapping of mild steel, cast iron and forged steel.

Specifications

SKU	Product Name	Vendor SKU	Chuck max capacity (in)	Reversible	Power Source	Sound Power (dB(A))	Sound Pressure (dB(A))	Uncertainty Vibration-k (ft/s²)	Air Consumption At Load (cfm)	Air Inlet Thread Size (in)	Max Dynamic Air Working Pressure (psi)	Min Hose Diam (mm)	Max power	Stall Torque (Nm)	Free Speed (rpm)	Length (in)	Tool Weight (lb)	Chuck Type	Handle type	Main Material type	Starting System	Air Inlet Thread Type
CI-6151580280	CP1820R22 - 7/8 in	6151580280	7/8	Yes	Pneumatic	109	98	3.9	42	1/2	90	0.5	1.19	57.8	480	11.1	16	Morse taper 2	T-handle	Aluminum	Self return rolling throttle	NPT
CI-6151580290	CP1820R32 - 1-1/4 in	6151580290	1-1/4	Yes	Pneumatic	121	110	2.6	110	1/2	90	0.75	2.82	145	380	13.9	31.9	Morse taper 3	T-handle	Aluminum	Self return rolling throttle	NPT
