Chicago Pneumatic CP3109 Series – Angle Grinders

Chicago Pneumatic CP3109 Series – Angle Grinders

$1,144.00$1,264.00

Add to Cart
Chicago Pneumatic CP3109 Series – Angle Grinders
Chicago Pneumatic CP3109 Series - Angle Grinders
$1,144.00$1,264.00

Extremely Durable for Industrial Applications

An ergonomic and extremely durable angle grinder for Industrial applications requiring 4″(100) wheel.

  • Highest durability in demanding applications, up to 2,000 hours maintenance intervals
  • Streamlined safety lever
  • Governed motor for operator safety
  • Steel housing with an insulating composite over-housing for operator comfort and superior ergonomics
  • Standard or extended shaft

The CP3109 4″ (100 mm) Angle Grinders ensure high durability, allowing a maintenance interval of up to 2000 hours thank to its heavy duty bevel gear. Designed with a governed motor and streamlined safety level, it offers a strong safety level for operator. The powerful motor provides 0.8hp (600 W) and a free speed of 13,000 rpm. 2 models available: Standard and extended shaft.

Accessories

Specifications

SKU
Product Name
Vendor SKU
Shaft Length
Free Speed (rpm)
Max power
Output Spindle Thread
Power Source
Air consumption at free speed (cfm)
Guard Max Rotation (°)
Wheel/Disc diameter (in)
Sound Power (dB(A))
Sound Pressure (dB(A))
Uncertainty Vibration-k (ft/s²)
Vibration (m/s²)
Air Consumption At Load (cfm)
Air Inlet Thread Size (in)
Max Dynamic Air Working Pressure (psi)
Min Hose Diam (mm)
Length (in)
Tool Weight (lb)
Autobalancer
Main Material type
Rotative Guard Type
Spindle Lock
Starting System
Swiveling Guard
Air Inlet Thread Type
CI-6151607030
CP3109-13A4 - Standard
6151607030
Standard
13000
0.8
3/8-24
Pneumatic
21
360
4
96
85
9.8
30.5
32
3/8
90
0.38
8.54
2.65
No
Aluminium, Composite over-sleeve
Band
No
Safety lever
Key
BSP
CI-6151607040
CP3109-13A4ES - Extended
6151607040
Extended
13000
0.8
3/8-24
Pneumatic
21
360
4
95
84
7.9
23.6
32
3/8
90
0.38
11.3
3.31
No
Aluminium, Composite over-sleeve
Band
No
Safety lever
Key
BSP
