Chicago Pneumatic CP6120 Series – Impact Wrenches

Chicago Pneumatic CP6120 Series – Impact Wrenches

$5,759.00$5,915.00

Add to Cart
Chicago Pneumatic CP6120 Series – Impact Wrenches
Chicago Pneumatic CP6120 Series - Impact Wrenches
$5,759.00$5,915.00

The Most Productive 1-1/2″

For heavy duty industrial users looking for medium to strong torque on soft and hard joints, the CP6120 Series – 1-1/2″, #5 impact wrench is strong enough to allow for intense use and is also comfortable due to low vibration levels.

  • Reliable 2-jaw clutch mechanism can be set for hard and soft joint applications
  • 2-jaw clutch minimizes vibration sensation
  • Robust steel clutch housing guarantees durability
  • High progressive max torque for smooth operation
  • Durable lightweight aluminium body offers operator comfort,

Improve assembly quality with this 1-12″/#5 impact wrench. With a heavy-duty 2-jaw clutch mechanism, an aluminium body, and a steel clutch housing, this tool is designed for comfort and durability. Delivers reverse torque up to 4,880 Nm / 3,600 ft.lb.
The CP6120 series is based on 2 models, hole or spline socket retainer.

Accessories

Specifications

SKU
Product Name
Vendor SKU
Output drive size (in)
Output drive type
Max Torque Reverse (ft.lbf)
Free Speed (rpm)
Tool Weight (lb)
Blow per minute (bpm)
Handle type
Power Source
Max Working Torque Fwd (ft.lbf)
Min Working Torque Fwd (ft.lbf)
Air Inlet Thread Size (in)
Max Dynamic Air Working Pressure (psi)
Min Hose Diam (mm)
Sound Power (dB(A))
Sound Pressure (dB(A))
Uncertainty Vibration-k (ft/s²)
Air consumption at free speed (cfm)
Length (in)
Side To Center (in)
Torque limited
Body
Clutch Housing
Clutch Lubrication Type
Impact Mecanism
Output retainer type
Side Handle
Starting System
Vibration (m/s²)
CI-6151590120
CP6120-D35H - Sq, 1-1/2 in
6151590120
1-1/2
Sq
3600
3500
34.5
960
D-handle
Pneumatic
2000
601
1/2
90
19
108
97
38.7
100
16.54
2.13
No
Aluminium
Steel
Grease
2-jaws
Hole
Yes
Trigger
-
CI-6151590130
CP6120-D35L - #5 Spline, #5 Spline in
6151590130
#5 Spline
#5 Spline
3600
3500
34.5
960
D-handle
Pneumatic
2000
601
1/2
90
19
108
97
38.7
100
16.54
2.13
No
Aluminum
Steel
Grease
2-jaws
Pin retainer
Yes
Trigger
21.8
