For users working in heavy vehicle tire changing applications who are looking for a 1″ D-handle impact wrench, the CP797 series offers both power & durability.

1,400 ft.lbs (1,898 Nm) of max torque in reverse position for high productivity
Metal housing and rocking dog impact mechanism for high durability and smooth operation
Convenient reverse valve and teasing trigger for better comfort in use

Designed for heavy vehicle tire changing applications, the CP797 Series 1″ impact wrench provides a torque of up to 1,400 ft.lbs / 1,898 Nm. The rocking dog impact mechanism and metal housing offer high durability for bolting applications. The CP797 series is available in 3 models: 1″ short anvil, 1″ long anvil (6″ anvil) and 1″ long anvil (6″ anvil) with spline retainer.

Shop the full range of pneumatic impact wrenches at Crowder Supply and see the related custom maintenance tools. It ships out of Denver, same day on in-stock orders placed before 4 PM ET.

Specifications

SKU	Product Name	Vendor SKU	Max Working Torque Fwd (ft.lbf)	Output drive size (in)	Anvil Extension	Max Torque Reverse (ft.lbf)	Free Speed (rpm)	Blow per minute (bpm)	Handle type	Power Source	Min Working Torque Fwd (ft.lbf)	Air Inlet Thread Size (in)	Max Dynamic Air Working Pressure (psi)	Min Hose Diam (mm)	Sound Power (dB(A))	Sound Pressure (dB(A))	Uncertainty Vibration-k (ft/s²)	Length (in)	Power Weight Ratio (Nm/kg)	Tool Weight (lb)	Torque limited	Vibration (m/s²)	Body	Clutch Housing	Clutch Lubrication Type	Impact Mecanism	Main Material type	Output drive type	Output retainer type	Side Handle	Starting System
CI-T019139	Chicago Pneumatic CP797 - 1 Inch Air Impact Wrench, D-Handle with Side Handle, Max Torque Reverse Output 1400 ft. lbf / 1890 Nm, 4200 RPM, Double Rocking Dog	T019139	900	1	None	1400	4200	1080	D-handle	Pneumatic	150	1/2	90	0.5	121	110	14.1	15.51	150	27	No	12.8	Aluminium	Aluminium	Oil bath	Double rocking dog	Aluminium	Sq	Dual	Yes	Trigger
CI-T013901	Chicago Pneumatic CP797-6 - 1 Inch Air Impact Wrench with 6 Inch Extended Anvil, D-Handle with Side Handle, Max Torque Reverse Output 1400 ft. lbf / 1890 Nm, 4200 RPM, Double Rocking Dog	T013901	904	1	6 Inch	1400	4200	1080	D-handle	Pneumatic	148	1/2	90	0.5	121	110	14.1	22.24	140	29.7	No	12.8	Aluminium	Aluminium	Oil bath	Double rocking dog	Aluminium	Sq	Friction ring	Yes	Trigger
CI-T018653	Chicago Pneumatic CP797SP6 - #5 Spline Air Impact Wrench with 6 Inch Extended Anvil, D-Handle with Side Handle, Max Torque Reverse Output 1400 ft. lbf / 1890 Nm, 4200 RPM, Double Rocking Dog	T018653	904	#5 Spline	6 Inch	1400	4200	1080	D-handle	Pneumatic	148	1/2	90	0.5	121	110	14.1	22.24	140	29.7	No	12.8	Aluminium	Aluminium	Oil bath	Double rocking dog	Aluminium	#5 Spline	Friction ring	Yes	Trigger
