Chicago Pneumatic CP886 Series – Ratchet Wrenches
Chicago Pneumatic CP886 Series - Ratchet Wrenches
$137.00

High Torque and Low Profile

For operators working in general maintenance who are looking for high torque and a low profile, the CP886 series offers a very compact head design.

  • Compact head design for improved access in tight places
  • Easy grip reverse for simple directional changes

The CP886 series pneumatic ratchet wrenches have a low profile head to ensure optimal fastening experience even in tight spaces. It delivers a maximum torque of up to 50 ft.lbs / 68 Nm. The CP886 series is composed of 2 models: 3/8″ and 1/2″ anvil.

Accessories

Specifications

SKU
Product Name
Vendor SKU
Output drive size (in)
Free Speed (rpm)
Max Torque Reverse (ft.lbf)
Length (in)
Vibration (m/s²)
Power Source
Max Working Torque Reverse (ft.lbf)
Min Working Torque Reverse (ft.lbf)
Tool Weight (lb)
Sound Power (dB(A))
Sound Pressure (dB(A))
Uncertainty Vibration-k (ft/s²)
Air Consumption At Load (cfm)
Air Inlet Thread Size (in)
Max Dynamic Air Working Pressure (psi)
Min Hose Diam (mm)
Main Material type
Output drive type
Output retainer type
Starting System
CI-T024240
CP886 - 3/8 in
T024240
3/8
160
50.2
10.24
3.7
Pneumatic
50.2
9.6
2.62
110
99
4.3
17
1/4
90
10
Aluminum
Sq
Ball detent
Lever
CI-T024391
CP886H - 1/2 in
T024391
1/2
160
50.2
10.24
3.7
Pneumatic
50.2
9.6
2.62
110
99
4.3
17
1/4
90
10
Aluminum
Sq
Ball detent
Lever
